Specifications

Dimensions:

Overall length:

2085 mm (82.1 in)

Overall width:

780 mm (30.7 in)

Overall height:

1105 mm (43.5 in)

Seat height:

805 mm (31.7 in)

Wheelbase:

1400 mm (55.1 in)

Ground clearance:

140 mm (5.51 in)

Minimum turning radius:

2.7 m (8.86 ft)

Weight:

Curb weight:

184 kg (406 lb)

Engine:

Combustion cycle:

4-stroke

Cooling system:

Liquid cooled

Valve train:

DOHC

Cylinder arrangement:

Inline

Number of cylinders:

2-cylinder

Displacement:

689 cm³

Bore × stroke:

80.0 × 68.6 mm (3.15 × 2.70 in)

Starting system:

Electric starter

Engine oil:

Recommended brand:

SAE viscosity grades:

10W-40, 10W-50, 15W-40, 20W-40 or 20W-50

Recommended engine oil grade:

API service SG type or higher, JASO standard MA

Engine oil quantity:

Oil change:

2.30 L (2.43 US qt, 2.02 Imp.qt)

With oil filter removal:

2.60 L (2.75 US qt, 2.29 Imp.qt)

Coolant quantity:

Coolant reservoir (up to the maximum level mark):

0.25 L (0.26 US qt, 0.22 Imp.qt)

Radiator (including all routes):

1.60 L (1.69 US qt, 1.41 Imp.qt)

Fuel:

Recommended fuel:

Unleaded gasoline (E10 acceptable)

Octane number (RON):

Fuel tank capacity:

14 L (3.7 US gal, 3.1 Imp.gal)

Fuel reserve amount:

2.7 L (0.71 US gal, 0.59 Imp.gal)

Fuel injection:

Throttle body:

ID mark:

1WS1

Drivetrain:

Gear ratio:

1st:

2.846 (37/13)

2nd:

2.125 (34/16)

3rd:

1.632 (31/19)

4th:

1.300 (26/20)

5th:

1.091 (24/22)

6th:

0.964 (27/28)

Front tire:

Type:

Tubeless

Size:

120/70 ZR 17M/C(58W)

Manufacturer/model:

MICHELIN/ROAD 5

Rear tire:

Type:

Tubeless

Size:

180/55 ZR 17M/C(73W)

Manufacturer/model:

MICHELIN/ROAD 5

Loading:

Maximum load:

171 kg (377 lb)

(Total weight of rider, passenger, cargo and accessories)

Front brake:

Type:

Hydraulic dual disc brake

Rear brake:

Type:

Hydraulic single disc brake

Front suspension:

Type:

Telescopic fork

Rear suspension:

Type:

Swingarm (link suspension)

Electrical system:

System voltage:

12 V

Battery:

Model:

YTZ10S

Voltage, capacity:

12 V, 8.6 Ah (10 HR)

Bulb wattage:

Headlight:

LED

Brake/tail light:

LED

Front turn signal/position light:

LED

Rear turn signal light:

LED

Auxiliary light:

LED

License plate light:

5.0 W
